Brand
- MFR #9500-08MM
- Zoro #G4611982
- Country of OriginChina
- Category
Dimensions
| Fits Bolt Sizes | M8 |
| Outside Dia. | 0.55 in |
| Inside Dia. | 0.34 in |
| For Screw Size | M8 |
| Dimensional Standards | DIN 7631, ISO 6149, ISO 9974 |
| Outside Diameter | 14 mm |
| Inside Diameter | 8.636 mm |
Details
| Item | Sealing Washer |
| Material | Steel/Buna-N |
| Finish | Cadmium Plated |
| Seal Material | Buna-N |
| Thickness | 1.3 mm |
| Standards | ISO1179-2, ISO 9974-2 |
| System of Measurement | Metric |
| Thickness Tolerance | +/-0.20mm |
| Application | Sealing |
| Type | Bonded |
| Seal Type | O-Ring |
| Color | Silver/Gold |
| Metal Material | Steel |
| Material Type | Steel |
| Sealing Washer Type | Metal Bonded Washer |
Description
Sealing Washer, Sealing Washer Type Metal Bonded Washer, Finish Cadmium Plated, Metal Material Steel, Material Grade/Class Not Graded, For Screw Size M8, Inside Diameter 8.636 mm, Outside Diameter 14 mm, Maximum Thickness 1.3 mm, Seal Material Buna-N, System of Measurement Metric, Pack Size Small Pack, Maximum Temperature 220 Degrees F, Minimum Temperature -40 Degrees F, Minimum Thickness 1 mm, Seal Material Color Silver/Gold, Thickness Tolerance +/-0.20 mm
